Product Features
- High repeatability.
- Generous range of motion.
- Rugged design for axial compliance.
- Energy absorption.
- Consistent break-away response.
- Flexible mounting surfaces.
- Automatic reset.
- Adjustable sensitivity.
- Optional spring provides two trip points.
- Optional Coolant Protection Boot (IP65-rated and made from fluoroelastomer for improved chemical resistance).
| Specification | Value |
|---|---|
| Angular Displacement | ±13° |
| Axial Break-away | 1700 N |
| Axial Displacement | 8.6 mm |
| Max Air Pressure | 6.2 bar |
| Moment Break-away Minimum | 14 Nm |
| Moment Break-away Maximum | 59 Nm |
| Torque Break-away | 61 Nm |
| Torsional Displacement | ±25° |
| Weight | 0.581 kg |
| Solid State Switch | No |
- Filter by Type
- Drawings
- Manuals
- Performance Data
| Download | Download Type | Language |
|---|---|---|
| SR-81 Collision Sensor | Drawings | English |
| SR-081 Collision Sensor Assembly Drawing | Drawings | English |
| SR-81 and SR-101 Switch Replacement Instructions | Manuals | English |
| SR-81, SR-101, SR-131, SR-176, and SR-221 C1 Boot and C2 Weld Shield Installation Instructions | Manuals | English |
| SR-48, SR-61, SR-81, SR-101, SR-131, SR-176, and SR-221 Installation Instructions for Coolant Protection Boot (C5) | Manuals | English |
| SR-81,SR-101,SR-131,SR-176, and SR-221 Collision Sensor Installation and Operation Manual | Manuals | English |
| SR-81 Collision Sensor Performance Data | Performance Data | English |
| Download | Description |
|---|---|
| SR-81 | SR-81 Collision Sensor |
- Filter by Part Number
- 8590-9909999-15
- 8590-9909999-07
- 8590-9909999-06
- 8590-9909999-48
- 8590-9909999-89
- 9160-C-3PF-4EM-050
| Part Number | Description | ||
|---|---|---|---|
 |
8590-9909999-15 | 3-pin Straight, Screw on Connector, High-Flex, Flying Lead, 5 Meter |
|
|
|
8590-9909999-07 | 3-pin Straight, Snap on Connector, High-Flex, Flying Lead, 5 Meter |
|
|
|
8590-9909999-06 | 3-pin 90 Degree, Snap on Connector, High-Flex, Flying Lead, 5 Meter |
|
|
|
8590-9909999-48 | 3-pin Straight, Screw on Connector, High-Flex, Flying Lead, 10 Meter |
|
|
|
8590-9909999-89 | 3-pin 90 Degree, Screw on Connector, High-Flex, Flying Lead, 10 Meter |
|
|
|
9160-C-3PF-4EM-050 | 3-pin Straight, Screw on Connector, High-Flex, 4-pin Euro (M12) Male Connector, 5 Meter |
|
